data sheet
ask a question |
|
|
No. of channels | analogue: | 2 - 24* (two-way radios, phones; Uin: 50 mV - 2 V) |
digital: | 2 - 24* (PBX system phones or ISDN BRI) | |
digital: | 8 - 30* (PRI E1) | |
VoIP: | 2 - 32** (audio codecs: G.711, G.722, G.729) | |
mixed: | 2 - 32** (analogue, digital except PRI, VoIP) | |
Number of interface board slots: | 6 | |
Hard disk drive: | 1 000+ GB optional software RAID 1 in the "HotSwap" rack automated RAID rebuild |
|
Recording buffer: | 30 000 h (for HDD 1 000 GB) | |
Supply: | 230 V AC | |
Power consumption: | 40 ... 100 W (according to equipment) | |
Input sockets: | RJ-12 | |
Display: | LCD 4 x 20 characters | |
Front panel operation: | 6 button keypad + access key | |
Network connectors: | 2 x Ethernet 100/1000 Mb/s (RJ-45) | |
Serial port: | 1 x USB 2.0 | |
Speaker: | built in the front panel | |
Dimensions: | 19″ 2U (RACK enclosure) |
* Number of interface board slots reduce hardware channels count to 24 or 30 (ISDN PRI).
** Value of 32 channels can be achieved only if the recorder is equipped with at least 8 VoIP channels
